6201 Full Zirconia Ceramic Bearing
| Place of Origin | Beijing, China |
|---|---|
| Brand Name | CSQ |
| Certification | FDA,REACH,ROHS,ISO9001,ISO14001,ISO45001 |
| Model Number | 6201ce |
| Minimum Order Quantity | 20-50 pcs |
| Price | Negotiable |
| Packaging Details | Foam+carton box |
| Delivery Time | 25-45 work days(negotiable) |
| Payment Terms | T/T |
| Supply Ability | 2000pcs per months |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | ZrO2 | Bearing Type | Full Ball Bearing |
|---|---|---|---|
| Percision | P6/ABEC3 To P4/ABEC7 | Characteristic | Long-lasting Life, Low Noise, High Precision |
| Application | Skateboard, Roller Skate, Water Pump | Clearance | C0-C5 |
| Number Of Row | Single Row | Structure | Deep Groove |
| Inner Diameter | 12mm | Out Diameter | 32mm |
| Width | 10mm | ||
| Highlight | 6201 zirconia ceramic bearing,full ceramic ball bearing,ceramic bearing with warranty |
||
Product Description
6201 Full Zirconia Ceramic Bearing with PTFE Cage
Product Overview
The 6201 Full Zirconia Ceramic Bearing is a high-performance deep groove ball bearing manufactured to international standard 6201 dimensions. It features inner ring, outer ring, and rolling elements made from high-purity Zirconia Ceramic, combined with a PTFE cage.
This unique material combination makes it the ultimate solution for extreme operating conditions involving corrosion, dry-running, high speeds, and electrical insulation, effectively solving common failures of traditional steel bearings related to corrosion, electrical erosion, and lubricant contamination.
Material and Properties
- Rings & Balls: High-Purity Zirconia Ceramic
- Exceptional corrosion resistance: Resists virtually all strong acids, alkalis, and organic solvents
- Electrical insulator: Prevents electrical pitting from VFD drives
- Non-magnetic: Ideal for precision instruments
- Low density & high hardness: 45% lighter than steel with excellent wear resistance
- High toughness: Superior impact resistance due to transformation toughening
- Cage: PTFE
- Superior self-lubrication with the lowest coefficient of friction
- Excellent chemical resistance matching Zirconia
- Non-stick surface with high-temperature capability (-200°C to +250°C)
The combination of PTFE cage with Zirconia balls results in very low friction and wear, outperforming metal-caged bearings significantly in dry or boundary lubrication states.
Working Principle
As a deep groove ball bearing, it supports shafts and reduces rotational friction via rolling contact. Its special materials introduce unique operational mechanisms:
- Creates an inert environment immune to chemical corrosion
- Enables maintenance-free operation with self-lubricating PTFE cage
- Blocks destructive currents, eliminating electrical pitting
- Handles high-speed operation with reduced centrifugal force
Technical Specifications
| Parameter | Description |
|---|---|
| Material | Ceramic: ZrO2 |
| Corrosion resistance | Excellent |
| Friction | Lower than steel |
| Wear resistance | Excellent |
| Temperature resistance | High |
| Strength | Higher than steel |
| Durability | Excellent |
| Weight | Lighter than steel |
| Precision | High |
| Biocompatibility | Some ceramic materials are biocompatible |
Application Scenarios
- Chemical & plating equipment: Resistant to strong acids and alkalis
- Food & pharmaceutical machinery: Meets hygiene requirements for lubricant-free operation
- Variable frequency drive motors: Serves as insulating bearing
- Semiconductor manufacturing: Prevents metallic contamination
- Precision instruments & medical devices: Non-magnetic, low-friction components
- High-temperature & vacuum environments: Reliable performance in extreme conditions
Why Choose Us
Professional Team
With our company logos ZXSQ and CSQ, we possess eleven invention patents for utility models. Our high-quality professional team provides customized bearing products according to customer requirements.
Since 1982, we have accumulated over 40 years of experience in ceramic bearing research, development, and production, becoming a leading enterprise in China's ceramic bearing market.
Strength Factory
We operate a fully automatic grinding and assembling production line with an annual output of 3 million sets of P5 and P4 precision level bearings. Our equipment includes a hot isostatic sintering furnace (HIP) imported from ABB Sweden, capable of reaching temperatures over 2000℃.
Master Raw Material Production Technology
We cooperate with raw material suppliers and maintain production technology to ensure product quality stability unaffected by international price fluctuations.
