Ceramic Silicon Carbide Ball Bearing Semiconductor Non Standard
| Place of Origin | China |
|---|---|
| Brand Name | CSQ |
| Model Number | Non-standard |
| Minimum Order Quantity | 50 pcs |
| Price | Negotiable |
| Packaging Details | Foam+cartom box |
| Delivery Time | Negotiable |
| Payment Terms | T/T |
| Supply Ability | Negotiable |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Customized Silicon Carbide Ball Bearing Of Non-Standard Type | Model | Non-standard |
|---|---|---|---|
| Race Material | SSiC (Silicon Carbide) | Ball Material | SSiC (Silicon Carbide) |
| Cage Material | Peek//PFA | Pacage | Foam+cartom Box |
| Highlight | silicon nitride ceramic ball bearing,arbide Ball Bearing Semiconductor,Ceramic Silicon Carbide Bearing |
||
Product Description
Customized Silicon Carbide Ball Bearing Of Non-Standard Type
Why choose us:
Our company is speciallizing in the production of ceramic rolling bearings and ceramic balls. In addition to the our mass production types-608, our company can according to the different needs of users, custom-make all ceramic bearings in material of silicon carbide of all precision levels, customized size range can be: inner diameter from 5 to 120mm, outer diameter from 10 to 200mm, including special non-standard size, special non-standard clearance.
Performance advantages of SSiC all ceramic bearings:
With a density and coefficient of linear expansion close to that of silicon nitride ceramic materials, high hardness, wear resistance, resistance to various strong acids, strong alkalis, salt corrosion, high temperature resistance. SSiC all ceramic bearings are preferred structure for the petroleum, chemical, semiconductor, food machinery, pharmaceutical industry, etc., and are the most widely used ceramic bearings.
| ►Key properties of pressureless sintered silicon carbide |
| ♦ Max Temperature up to 1650℃ |
| ♦ Low density:3.15-3.18 g/cm3 |
| ♦ High strength |
| ♦ Low thermal expansion : 4.0 (10-6/℃) |
| ♦ High thermal conductivity:120 W/m°K |
| ♦ High hardness:2800 HV5 |
| ♦ High elastic modulus: 410GPa |
| ♦ Superior chemical stability,resistance to acid and alkali corrosion (incld. hydrofluoric acid) |
