Ceramic High Speed Bearings Double Row Self Aligning 1201 1202 1203 1204 1205

  • Ceramic High Speed Bearings Double Row Self Aligning 1201 1202 1203 1204 1205
  • Ceramic High Speed Bearings Double Row Self Aligning 1201 1202 1203 1204 1205
Place of Origin China
Brand Name CSQ
Model Number 1200 series
Minimum Order Quantity 50 pcs
Price Negotiable
Packaging Details Foam+cartom box
Delivery Time Negotiable
Payment Terms T/T
Supply Ability Negotiable

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name 1200 Series Ceramic Double-Row Self-Aligning Ball Bearings Model 1200-1215 Series
Race And Balls Material Silicon Nitride Or Silicon Carbide Or Zirconia Cage Material Peek//PFA
Precision P6/ABEC3 To P4/ABEC7 Color White Or Black
MOQ 50 Pieces/one Model Pacage Foam+cartom Box
Highlight

ceramic self aligning bearings

,

High Speed Ceramic Bearings

,

Ceramic High Speed Bearings 1201
Leave a Message
Product Description



1200 Series Ceramic Double-Row Self-Aligning Ball Bearings Of Si3N4/SSiC/ZrO2



Why choose us:



Since the establishment of the company, we have been conducting continuous innovation research and development on ceramic rolling bearings and relevant automatic production. At present, our company has been able to produce many models of ceramic bearings of silicon nitride, pressureless sintering silicon carbide and zirconia ceramic materials. Welcome your inquiry.



Material properties of ceramic material:



Material Properties Units SSiC HIP-Si3N4 GPS-Si3N4 HIP-ZrO2
Density g/cm3 3.15-3.18 3.27-3.29 3.22-3.27 6.05-6.09
Porosity % 0 0 0 0
Fledural Strength MPa 550 830 689 900
Elastic Modulus GPa 410 310 310 200
Hardness HV5 2800 1580 1450 1300
Fracture Toughness KIC MPa.m1/2 4.6 6.1 5.7 8-11
Maximum Use Temperature

℃
(℉)

1650
(3000)

1000
(1830)

1000
(1830)

380
(716)


Reference data of 1200 series Ceramic Double-row Self-aligning Balls Bearings:



Bearings model

Form size
d (mm)

Form size
D (mm)

Form size
B (mm)

Load
Cr (N)

Load
Cor (N)

Max.Speed
Grease (rpm)

Max. Speed
Oil (rpm)
1200CE 10 30 9 4950 1190 27300 31200
1201CE 12 32 10 5040 1270 23400 28600
1202CE 15 35 11 6710 1750 20800 24700
1203CE 17 40 12 7110 2010 18200 22100
1204CE 20 47 14 8910 2610 16900 19500
1205CE 25 52 15 10890 3300 14300 16900
1206CE 30 62 16 14040 4650 11960 14300
1207CE 35 72 17 14220 5100 10400 12220
1208CE 40 80 18 17370 6550 9230 10920
1209CE 45 85 19 19710 7350 8320 9750
1210CE 50 90 20 20430 8100 7540 8840
1211CE 55 100 21 24120 10000 6890 8060
1212CE 60 110 22 27000 11500 6370 7540
1213CE 65 120 23 27900 12500 5850 6890
1214CE 70 125 24 31050 13800 8460 6370
1215CE 75 130 25 35100 15700 5070 5980
