Zr Zirconium Zirconia Bearing Ball High Precision NU200 NU300 Series

  • Zr Zirconium Zirconia Bearing Ball High Precision NU200 NU300 Series
  • Zr Zirconium Zirconia Bearing Ball High Precision NU200 NU300 Series
Place of Origin China
Brand Name CSQ
Model Number NU200/NU300 SERIES
Minimum Order Quantity 50 pcs
Price Negotiable
Packaging Details Plastik bag+foam+carton box
Delivery Time 45-60 work days
Payment Terms T/T
Supply Ability 50 pcs in 45-60 work days

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Zirconia Roller Bearings Material ZrO2 Races And Rollers + PTFE Cage
Model NU200/NU300 Series Size According To The Model
Precision P6/ABEC3 To P4/ABEC7 Use Chemical Industry
Pacage Plastik Bag+foam+carton Box MOQ 50 Pieces
Highlight

zirconia ceramic ball

,

zirconium bearing

,

zr bearing
Leave a Message
Product Description



Customized Zirconia Roller Bearings With High Precision



Description of Zirconia Roller Bearings



1. Our zirconia material are highly purified, sub-micron and after Y2O3 partially stabled zirconia powder material and are precessed by GPS or HIP sintering technology.



2. Cage: The material of cage, which are be fitted in the zirconia ceramic roller bearings can be chosen among and PEEK, of course, we can produce full roller structure. and PEEK material both have excellent chemical stability, are resistant to many kinds of acid and alkali corrosion.



Performance advantages of Zirconia Roller Bearings



Zirconia bearings have many advantages, such like High density: 6.09 g/cm3, Low thermal conductivity, Good chemical stability, resistance to acid and alkali corrosion and excellent wear resistance, High fracture toughness KIC:8-11 MPa-m1/2, Good electric insulation



Bearings model Form size
d (mm)		 Form size
D (mm)		 Form size
B (mm)		 Load
Cr (N)		 Load
Cor (N)		 Max.Speed
Grease (rpm)		 Max. Speed
Oil (rpm)
NU202CE 15 35 11 12500 10200 18000 28600
NU302CE 15 42 13 19400 15300 16000 24700
NU203CE 17 40 12 17200 14300 16000 24700
NU303CE 17 47 14 24600 20400 14000 22100
NU204CE 20 47 14 25100 22000 13000 20800
NU304CE 20 52 15 30800 26000 12000 19500
NU205CE 25 52 15 28600 27000 11000 18200
NU305CE 25 62 17 40200 36500 9500 15600
NU206CE 30 62 16 38000 36500 9500 15600
NU306CE 30 72 19 51200 48000 9000 14300
NU207CE 35 72 17 48400 48000 8500 13000
NU307CE 35 80 21 64400 63000 8000 12350
NU208CE 40 80 18 53900 53000 7500 11700
NU308CE 40 90 23 80900 78000 6700 10400
NU209CE 45 85 17 60500 64000 6700 10400
NU309CE 45 100 25 99000 100000 6300 9750
NU210CE 50 90 20 64400 69500 6300 9750
NU310CE 50 110 27 110000 112000 5000 7800
NU211CE 55 100 21 84200 95000 6000 9100
NU311CE 55 120 29 138000 143000 4800 7280
NU212CE 60 110 22 93500 102000 5300 8190
NU312CE 60 130 31 151000 160000 4300 6500
NU213CE 65 120 23 106000 118000 4800 7280
NU313CE 65 140 33 183000 196000 4000 6240
NU214CE 70 125 24 119000 137000 4500 6890
NU314CE 70 150 35 205000 228000 3600 5590
NU215CE 75 130 25 130000 156000 4500 6890
NU315CE 75 160 37 242000 265000 3400 5200
NU216CE 80 140 26 138000 166000 4000 6240
NU316CE 80 170 39 260000 290000 3200 4340
NU217CE 85 150 28 165000 200000 3800 5850
NU317CE 85 180 41 297000 335000 3000 4680



Zr Zirconium Zirconia Bearing Ball High Precision NU200 NU300 Series 0
